What kind of sonar?
Multibeam - Environment, Applications
Inland, Smaller Areas, Good Resolution
Shallow water (0.5 to 100m)
Bathymetry
Smaller survey areas
Reliable Performance, Ease-of use
Good Resolution, Good data quality
Budget Options
Rivers, Ponds, Lakes, Marinas, Mining
Inland or Offshore, Larger Survey Areas, High Resolution
Shallow to Mid-water (0.5m to 500m)
Bathymetry, Backscatter, Water Column
Many additional features and options
Superior Data Quality
Highest Resolution
Widest Swath - maximum productivity
Lakes, Offshore, Infrastructure, Marine Construction, Feature detection
Survey Boat or USV, or Both
Do you want Hydrographic payload equipment to be used on/off a remote-controlled Uncrewed Surface Vessel (USV)?
1-2 person portable
Davit or trailer launch
Single Beam Echosounders - SBES
SBES - EchoSounder on a Stick
- 0.1m to 100m
- Affordable
- Integrates w/ standard land surveyors data loggers and field software
- Single or Dual Frequency
- Raw water-column Echogram output
Ideal for Land Surveyors
SBES - Portable, Shallow Water
- 0.1m to 200m
-One-box splash-proof solution with internal battery and data logging
- Single or Dual Frequency
- Optional RTK GPS included
- Compatible with HYPACK, QPS, HydroMagic, Chesapeake
When portability and ease of deployment is critical
SBES - High Power, Permanent Install
- 0.5 to 6000m
- Superior penetration into sediment
- Great for permanent installations
- Ideal for dynamic dredging environments
Multibeam Echosounders - MBES
MBES - Underwater Point Cloud Mapper for Geospatial User
- 0.5 to 40m depths
- 130° swath
- 4x water depth coverage
- 1.4° x 1.7° degree angular resolution
- 512 beams
- 400kHz
- 1.7kg Compact, Portable
- No Topside !
- Outputs Georeferenced XYZ data ready for processing
MBES - Affordable, Entry-level for Hydrography
- 0.5 to 100m depths
- 130° swath
- 4x water depth coverage
- 1.0° x 1.4° degree angular resolution
- 512 beams
- 400-550kHz
- 3.5kg Compact, Portable
- Why pay for bells and whistles you dont need?? Just get it done.
MBES - Very Shallow water, High-resolution, high productivity
- Very Shallow water applications (0.3 to 10m)
- Swath as wide as 220°
- 12-16x water depth coverage
- 1024 beams
MBES - High Resolution, High Productivity
- 0.5 to 500m
- 170°-210° swath
- 7x water depth coverage
- 1.0° x 1.0° degree angular resolution
- 1024 or more beams
- 200-400kHz frequency agile
- Excellent Data Quality
- Advanced User Interface
- Advanced features and options
CONTACT FOR MORE INFO AND PRICING IN THIS RANGE
MBES - Ultra-High Resolution, Supreme Data Quality
- 0.5 to 500m
- 170°-210° swath
- 7x water depth coverage
- 0.25° x 0.5° degree angular resolution
- 1024 or more beams
- 200-800kHZ
- Superior Data Quality
- Advanced User Interface
- Advanced features and options
- Highest resolution option on the market
CONTACT FOR MORE INFO AND PRICING IN THIS RANGE
Uncrewed Surface Vessels (USV's)
USV - 1-person Portable
- Autonomous mission planning
- Carried by 1-2 people
- Multibeam or Single Beam
- Minimal onsite assembly
- 2-3' waves/chop
- 6knot max speed
- 2.5knot typical survey speed
- 18 hours duration
- >10km controller range
- >10km communication range
- Cellular option
- Integrated Camera
- 17kg (37lbs) w/ batteries
- Payload 15 kg (33 lb)
- 47 x 36.5 x 18 in (Deployed)
- Affordable
- Applications: Mining, ponds, rivers, marinas, inspection
USV - Inland Nearshore
- Autonomous mission planning
- Trailerable, or assembled on site in 60min
- Multibeam or Single Beam
- Operates in SS3 conditions
- 6knot max speed
- 3knot typical survey speed
- 10 hours duration at survey
- Cellular, Starlink Comms
- Integrated Camera
- 250lbs with batteries
- Payload capable: 100lbs
- 8' x 4'
USV - Nearshore, Offshore
- Autonomous mission planning
- Trailerable
- Multibeam, SBP
- Operates in SS4 conditions
- 11knot max speed
- 5knot typical survey speed
- 15 hours duration at survey
- Cellular, Starlink Comms
- Integrated Camera
- 450lbs with batteries
- Payload capable: 250lbs
- 16' x 8'
USV - Nearshore, Offshore 3 -Day Endurance, High Speed
- 0.5 to 500m
- 170°-210° swath
- 7x water depth coverage
- 1.0° x 1.0° degree angular resolution
- 1024 or more beams
- 200-400kHz frequency agile
- Excellent Data Quality
- Advanced User Interface
- Advanced features and options
CONTACT FOR MORE INFO AND PRICING IN THIS RANGE
Ancillary Equipment & Software
Inertial Navigation Systems
Applanix Surfmaster
Applanix Wavemaster
Applanix Oceanmaster
POSPac
